The superior solution for saving energy

EARTHLIFT

Recognized as the industry’s first “green” mobile column lift, EARTHLIFT columns are made from components that are 98% recyclable, use bio-degradable oil, feature batteries that are 100% recyclable, and employ an Active Energy Retrieval System to deliver 35% more lifting cycles at maximum load. Lifting capacities range from 18,000 lbs. to 22,000 lbs. per column.

EARTHLIFT Brochure
  • Environmentally-friendly
  • Wireless as standard
  • Full-color touch screen control as standard
  • Biodegradable fluid is contained
  • Recyclable batteries
  • Operator can see savings in real-time

Specifications

ModelST 1085ST 1100
Lifting capacity18,500 lbs.22,000 lbs.
Lifting height73 inches73 inches
Lifting time94 seconds94 seconds
Fork typeAdjustableAdjustable
Fork length14 inches14 inches
ebright Smart Control SystemYesYes
Adjustable lowering speed YesYes
Lifting capacity18,500 lbs.Lifting height73 inchesLifting time94 secondsFork typeAdjustableFork length14 inchesebright Smart Control SystemYesAdjustable lowering speed Yes
Lifting capacity22,000 lbs.Lifting height73 inchesLifting time94 secondsFork typeAdjustableFork length14 inchesebright Smart Control SystemYesAdjustable lowering speed Yes

The Green Standard in HD Lifting

EARTHLIFT: A superior heavy duty lifting solution that is mobile, environmentally friendly, safe, fast and secure.  Combine the best in green lifting technology with the power and ease-of-use found in all Stertil-Koni lifting systems.

Plus, enjoy the benefits of a full-color touch screen control console – the ebright Smart Control System – which comes as standard on the EARTHLIFT and delivers maximum information in real-time.  Capture up to 50 lifting cycles without battery charging and optimize productivity in your workshop.

Stertil-Koni EARTHLIFT ebright



Active Energy Retrieval System (AERS)

The principle of the Active Energy Retrieval System (AERS) is as brilliant as it is simple: to use the energy generated by the raised vehicle as it comes back down. In other words: regain the gravitational energy.

18,500 or 22,000 lbs

Both 18,500 or 22,000 lbs EARTHLIFT models are ideal for different situations. The 18,500 lbs EARTHLIFT model for example is ideal for super single tyres. For fleets or wokshops requiring extra lifting capacity, there is the 22,000 lbs EARTHLIFT model.

Life Guarantee

The patented synthetic runner wheel system is self-lubricating and therefore does not require any maintenance. Stertil-Koni offers a lifetime guarantee on this system

Simply Recharging

Although recharging is less frequent with the EARTHLIFT, each column is fitted with two deep cycle marine batteries which can simply be recharged with a 110VAC receptacle energy source

Recycable

The EARTHLIFT is the most environmentally-friendly wireless mobile column lift in the world.

  • Lifting column made of recyclable components
  • Biodegradable oil in a closed hydraulic system
  • Batteries are recyclable
  • 18,500 or 22,000 lbs
  • Life Guarantee
  • Simply Recharging
  • Recycable

Minimum Repair, Minimum Damage

Totally cable-free, Stertil-Koni EARTHLIFT eliminates potentially expensive repair bills of damaged cables and offers ultimate safe working conditions as there are no tripping hazards caused by cabled over the workshop floor.

Full-colour Touch Screen control

The revolutionary ebright smart control system combines intuitive ease of use with maximum visual information about the lifting process.

The 7” full colour high resolution touch screen is also operational when wearing gloves. With the user ID key, the user can configure the system to its personal needs.

Maximum Mechanical Safety

Independent mechanical gravity locking pawl; starts at 125 mm. Minimal incremental locking profile with 35 mm increments, the smallest available in the industry. Vehicle damage prevention due to 250 mm distance between lift and vehicle. Precision synchronisation starts at 15 mm height difference between the lift and the vehicle

Maximum Control Safety

Individual user settings for choosing language and units. Protection against unauthorised use with personalised ID key. Visual display of maximum programmable lifting height

The perfect Green system to lift your Heavy Duty Vehicle
